Settings

(1) URL/Variables: Here you can specify a local path to an image file (relative to folder ./webapps/root). Example: You have to enter /upload/myimages/test.png for the file ./webapps/root/upload/myimages/test.png. Note: See section File upload.

Another option is to enter a URL to an image. Example: https://example.com/img/image.jpg


Alternatively, you can select a workflow variable via the icon on the right. To do this, this variable must be filled in a previous state via a signature field, for example.

(2) Attributes: CSS properties can be inserted via the context menu. Some are already selectable:
